ZXR10ZSRV2HardwareDescription

PropertyDescription

Supportednetwork

protocol

Indicators

ForadescriptionoftheindicatorsoftheRAC-PIU-04SHDSLboard,refertoT able9-26.

Table9-26DescriptionoftheIndicatorsonthePaneloftheRAC-PIU-04SHDSLBoard

IndicatorColorDescription

RUNGreenTheindicatorislitwhentheboardisoperatingproperly.

ALMRedTheindicatorislitiftheboardproducesanalarm.

LNK/ACTGreen,Yellow

Linkstatus/datatransmissionindicator:

lIfthelinkisnormal,theindicatorislitingreen.

lIfdataisbeingtransmitted,theindicatorashesinyellow.

lIfthereisnodatabeingtransmittedornoconnection,the

indicatorisnotlit.

TechnicalParameters

ForthetechnicalparametersoftheRAC-PIU-04SHDSLboard,refertoT able9-27.

Table9-27TechnicalParametersoftheRAC-PIU-04SHDSLBoard

ParameterSpecication

SilkscreennameRAC-PIU-04SHDSL

Dimensions(W×H×D)7.76in.×0.79in.×6.9in.(197.2mm×19.92mm×175mm)

Powerconsumption10W

Weight1.19lb.(0.54kg)

Rate5.696Mbit/s/pair

9.10RAC-PIU-04HS

Overview

RAC-PIU-04HSboardprovidesthefollowingfunctions:

lProvides4-wireserialportssupportingasynchronousorsynchronousdata

transmissionmode.

àForsynchronousdatatransmissionmode,theportscanbeconnectedtoDTEs

orDCEs.ThecircuitsidesupportstheV.24,V.35,orX.21interfaces.TheV.24

interfacesupportsamaximumrateof115.2Kbps.TheV.35interfacesupports

9-16

SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential
