Chapter9LineInterfaceBoards

PropertyDescription

Supportednetwork

protocol

Indicators

ForadescriptionoftheindicatorsoftheRAC-SPIU-02HSboard,refertoT able9-15.

Table9-15DescriptionoftheIndicatorsonthePaneloftheRAC-SPIU-02HSBoard

IndicatorColorDescription

RUNGreenTheindicatorislitwhentheboardisoperatingproperly.

LNK1/LNK2Green

Theindicatorislitwhenthelinkisoperatingproperly,andis

notlitwhenthelinkisidle.

TechnicalParameters

ForthetechnicalparametersoftheRAC-SPIU-02HSboard,refertoT able9-16.

Table9-16TechnicalParametersoftheRAC-SPIU-02HSBoard

ParameterSpecication

SilkscreennameRAC-SPIU-02HS

Dimensions(W×H×D)3.86in.×0.79in.×6.9in.(98.1mm×19.92mm×175mm)

Powerconsumption7W

Weight0.46lb.(0.21kg)

RateMultiplerates,upto4.096Mbps.

9.6RAC-SPIU-04GE

Overview

AnRAC-SPIU-04GEboardhasthefollowingfunctions:

lProvidesfourlinesofelectricalinterfacesforgigabitEthernetinterfacecards.

lSupportsself-adaptive10/100/1000BASE-T.

lSupportshopswappingofboards.

lSupportsboardtemperaturedetectionandboardIDread.

Panel

ForthepanelofanRAC-SPIU-04GEboard,seeFigure9-6.

9-9

SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential
