Zte ZXR10 3800-8 User Manual

Chapter9LineInterfaceBoards
9.26RAC-PIU-08FE1GE-1SFP
Overview
RAC-PIU-08FE1GE-1SFPboardprovidesthefollowingfunctions:
lProvideseightFEelectricalinterfacesandoneGEopticalinterface.
lTheFEelectricalinterfacessupport100BASE-TXandtheGEopticalinterfacesup-
ports1000BASE-X.
lSupportshotswapping.
lSupportsboardinformationqueryandtemperaturemonitoring.
Panel
ForthepaneloftheRAC-PIU-08FE1GE-1SFPboard,seeFigure9-26.
Figure9-26FrontPaneloftheRAC-PIU-08FE1GE-1SFPBoard
InterfaceProperties
TheRAC-PIU-08FE1GE-1SFPboardprovideselectricalandopticalinterfaces(FE1–FE8,
GE1),whicharedistinguishedbysilkscreenname.Theycanbealsodistinguishedbythe
interfaceoverviewandindicators.
ForadescriptionoftheFEelectricalinterfacepropertiesoftheRAC-PIU-08FE1GE-1SFP
board,refertoTable9-78.
Table9-78GEElectricalInterfacePropertiesoftheRAC-PIU-08FE1GE-1SFPBoard
PropertyDescription
ConnectortypeRJ45
OperationalmodeFullduplex,Halfduplex
AppliedstandardIEEE802.3uFastEthernetstandard
SupportedframeformatEthernetframe
Supportednetwork
protocol
IP
TheRAC-PIU-08FE1GE-1SFPboardusesSFPopticalmodules.Foradescriptionofthe
opticalinterfaceproperties,refertoTable9-79.
Table9-79OpticalInterfacePropertiesoftheRAC-PIU-08FE1GE-1SFPBoard
PropertyDescription
ConnectortypeLC-typeSFPopticalmoduleinterface
9-41
SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential
