ZXR10ZSRV2HardwareDescription

Table9-30TechnicalParametersoftheRAC-PIU-04HSBoard

ParameterSpecication

SilkscreennameRAC-PIU-04HS

Dimensions(W×H×D)7.76in.×0.79in.×6.9in.(197.2mm×19.92mm×175mm)

Powerconsumption10W

Weight1.19lb.(0.54kg)

Rate1200bps–4.096Mbps×4

9.11RAC-PIU-04CE1-75

Overview

RAC-PIU-04CE1-75boardprovidesthefollowingfunctions:

lProvidesfourchannelized/unchannelizedE1(75ohm)interfaces.

lRestoresthelineclockandprovidingittoanMPFUboardforreference.

lSupportstheprocessingofvariousservices,suchasPPPandML-PPP.

lSupportshotswapping.

lSupportsboardinformationqueryandtemperaturemonitoring.

Panel

ForthepaneloftheRAC-PIU-04CE1-75board,seeFigure9-11.

Figure9-11FrontPaneloftheRAC-PIU-04CE1-75Board

InterfaceProperty

TheRAC-PIU-04CE1-75boardprovidesmicrocoaxialinterfaces,anditonlysupports75

ohmnon-balancedE1interfaces.Foradescriptionoftheinterfaceproperties,referto

Table9-31.

Table9-31InterfacePropertiesoftheRAC-PIU-04CE1-75Board

PropertyDescription

ConnectortypeMicrocoaxial

OperationalmodeFullduplex

AppliedstandardITU-TG.703,G.704

SupportedlinkprotocolPPP ,ML-PPP ,HDLC,FR

9-18

SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential
