ZXR10ZSRV2HardwareDescription

Table9-46InterfacePropertiesoftheRAC-PIU-16CE1-CESBoard

PropertyDescription

ConnectortypeDB50

OperationalmodeFullduplex

AppliedstandardITU-TG.703,G.704

SupportedlinkprotocolTDM

Indicators

ForadescriptionoftheindicatorsoftheRAC-PIU-16CE1-CESboard,refertoTable9-47.

Table9-47DescriptionoftheIndicatorsonthePaneloftheRAC-PIU-16CE1-CESBoard

IndicatorColorDescription

RUNGreenTheindicatorislitwhentheboardisoperatingproperly.

ALMRedTheindicatorislitiftheboardproducesanalarm.

TechnicalParameters

ForthetechnicalparametersoftheRAC-PIU-16CE1-CESboard,refertoTable9-48.

Table9-48TechnicalParametersoftheRAC-PIU-16CE1-CESBoard

ParameterSpecication

SilkscreennameRAC-PIU-16CE1-CES

Dimensions(W×H×D)7.76in.×0.79in.×6.9in.(197.2mm×19.92mm×175mm)

Powerconsumption16W

Weight1.19lb.(0.54kg)

Rate2.048Mbps×16

9.17RAC-PIU-01P12-SFP

Overview

RAC-PIU-01P12-SFPboardprovidesthefollowingfunctions:

lSupports1-wireOC-12/STM-4POSapplications.

lSupportstheprocessingofvariousservices,suchasPPPandHDLC.

lSupportshotswapping.

lSupportsboardinformationqueryandtemperaturemonitoring.

Panel

ForthepaneloftheRAC-PIU-01P12-SFPboard,seeFigure9-17.

9-26

SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential
