ZXR10ZSRV2HardwareDescription

InterfaceProperties

TheRAC-PIU-04P3-SFPboardusesSFPopticalmodules.Foradescriptionofthe

interfaceproperties,refertoT able9-55.

Table9-55InterfacePropertiesoftheRAC-PIU-04P3-SFPBoard

PropertyDescription

ConnectortypeLC-typeSFPopticalmoduleinterface

OperationalmodeFullduplex

AppliedstandardSONETGR-253-CORE/ITU-TG.707

SupportedlinkprotocolPPP ,HDLC,FR,POSGROUP

Supportednetwork

protocol

Indicators

ForadescriptionoftheindicatorsoftheRAC-PIU-04P3-SFPboard,refertoT able9-56.

Table9-56DescriptionoftheIndicatorsonthePaneloftheRAC-PIU-04P3-SFPBoard

IndicatorColorDescription

RUNGreenTheindicatorislitwhentheboardisoperatingproperly.

ALMRedTheindicatorislitiftheboardproducesanalarm.

LNK/ACTGreen/Yellow

Linkstatus/datatransmissionindicator:

lIfthelinkisnormal,theindicatorislitingreen.

lIfdataisbeingtransmitted,theindicatorashesin

yellow.

lIfthereisnodatabeingtransmittedornoconnection,

theindicatorisnotlit.

TechnicalParameters

ForthetechnicalparametersoftheRAC-PIU-04P3-SFPboard,refertoT able9-57.

Table9-57TechnicalParametersoftheRAC-PIU-04P3-SFPBoard

ParameterSpecication

SilkscreennameRAC-PIU-04P3-SFP

Dimensions(W×H×D)7.76in.×0.79in.×6.9in.(197.2mm×19.92mm×175mm)

Powerconsumption18W

Weight1.19lb.(0.54kg)

Rate155.52Mbps×4

9-30

SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential
