Zte ZXR10 3800-8 User Manual

Chapter10Cables
RJ45
Pin
PCBAUX
Signal
Signal
Direction
DB9PinPCDB9(Hole)
Signal
ModemDB-9
(Pin)Pin
ModemDB-9
(Pin)Signal
7DSR←4DTR6DSR
8RTS→8CTS7RTS
10.2.2ConsoleCables
ConnectingtheZXR10ZSRV2consoleporttotheconsoleserialport,theconsolecable
transmitsdevicecongurationdata.
Theconsolecommunicationcableisan8-coreshieldedcable.Oneendofthecableis
anRJ45connectorconnectingtotheMPUconsoleport.Theotherendconnectstothe
serverserialport.
Fortheoverviewoftheconsolecable,seeFigure10-5.
Figure10-5ConsoleCableStructure
1.D-type9-coreplastic
injectionmoldedcableplug
(hole)
2.Label/self-coveringwinder
laserprint(typeII)
3.Horizontaltwistedpair
SBVVP-2×2
4.8P8Cstraightcablesolder
connector
Fortherelationshipbetweenconsolecablecorewiresandpinpositions,refertoTable
10-5.
Table10-5CoreWiresofaConsoleCable
RJ45PinPCBCONSOLE
Signal
Signal
Direction
DB9PinPCDB9(Hole)
Signal
1Nosignalincaseof
threewires
←7RTS
2Nosignalincaseof
threewires
→6DSR
3TXD→2RXD
4GND←1DCD
10-5
SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential

Zte ZXR10 3800-8 Specifications

General

MAC Address Table Size	16K
VLAN	4K
MAC Address Table	16K
Packet Buffer	4 MB
Storage Temperature	-40°C to 70°C
Dimensions	440mm x 220mm x 44mm
Power Supply	AC: 100V~240V, 50/60Hz
Operating Temperature	0°C to 45°C
Operating Humidity	10% to 90% RH
Ports	8x 10/100/1000Base-T, 4x SFP
Power Consumption	Max 30W
