ZXR10ZSRV2HardwareDescription

Table8-1DescriptionsofInterfacesontheRAC-DPIU-OSU-A1Board

InterfaceTypeDescription

Networkinterface(RJ45)Servicenetworkinterface,a10/100/1000BASE-Telectricalinterface.

Serialinterface(RJ45)SerialinterfaceinterconnectedwithaPC.

VGAinterface(DB15)X86VGAoutputinterface.

USBinterfacesUSB2.0interfacesusedtoinstalltheX86system.

Indicators

TheRAC-DPIU-OSU-A1boardprovidesmultipleLEDindicatorsonitspanel.Fortheir

functions,refertoTable8-2.

Table8-2FunctionsoftheIndicatorsonthePaneloftheRAC-DPIU-OSU-A1Board

IndicatorColorDescription

ALMRedIfthisindicatorissolidonorashing,theboardis

faulty.

RUNGreenIndicatesthattheboardisoperatingproperly.

Buttons

TheRAC-DPIU-OSU-A1boardprovidestwobuttonsonitspanel.Fortheirfunctions,refer

toTable8-3.

Table8-3FunctionsoftheButtonsonthePaneloftheRAC-DPIU-OSU-A1Board

ButtonDescription

RSTBoardresetbutton

PWRBoardpowerbutton

TechnicalParameters

FortechnicalparametersoftheRAC-DPIU-OSU-A1board,refertoTable8-4.

Table8-4TechnicalParametersoftheRAC-DPIU-OSU-A1Board

ParameterDescription

BoardnamesilkscreenRAC-DPIU-OSU-A1

Dimension(width×height×depth)7.76in.×1.58in.×6.9in.(197.2mm×40.24mm

×175mm)

Powerconsumption40W

Weight2.71lb.(1.23kg)

MemoryDefaultcapacity(byte)4Gor8G(optional)

HarddiskDefaultcapacity(byte)500Gor1T(optional)

8-2

SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential
