Chapter5

ZXR102800-3EChassis

TheZXR10ZSRV2serialroutershaveastructuredesignedbasedonmodularization.The

boardsandcomponentssupportonlinehotswappingandhaveaexibleexpendability.

AZXR102800-3Echassisiscomposedofasubrack,abackplane,acontrollingand

transferringunit,lineinterfaceboards,powermodules,andfanmodules.

TheZXR102800-3Esubrackhasasheetmetalstructure.Whereinthecontrollingand

transferringunitandfanmodulesarexedonaZXR10ZSRV2router,theserviceboard

andpowermodulesareinstalledattheback,cablesareledoutfromtheback,andthree

lineinterfaceboardscanbeinstalled.TheentireZXR102800-3Echassishasastandard

widthof19"andcanbeinstalledintoastandardIEC297cabinetoranETSIcabinet.

AZXR102800-3E(G)submodelcanbederivedfromaZXR102800-3Echassisby

expandingthewirelessfunctionmodule.TheZXR102800-3E(G)submodelhasa3Gor

LTEmoduleinsideandaslotforaSIMcardonthepanel,supportingaGSM,WCDMA,

TD-SCDMA,orLTEnetwork.

TableofContents

Structure....................................................................................................................

5-1

PowerSupplies..........................................................................................................5-5

5.1Structure

5.1.1OverviewandStructure

Overview

AchassisofaZXR102800-3Erouterhasaheight(withouttheantenna)ofabout1U

(1U=44.45mm),andadimensionof442mm×44mm×440mm(width×height×depth).

Foritscomponentsanddescriptions,refertoT able5-1.

Table5-1MainComponentsofaZXR102800-3EChassis

ComponentDescription

Controllingandtransferring

board

Integratedontherouterandcannotbepluggedorunplugged.

BoardsTheZXR102800-3Echassisprovidesthreeslotsforlineinterface

boards.

PowermodulesTheZXR102800-3Echassisprovidestwoslotsforoneortwo

powermodules.

5-1

SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential
