Chapter9LineInterfaceBoards

Table9-44DescriptionoftheIndicatorsonthePaneloftheRAC-PIU-16CE1Board

IndicatorColorDescription

RUNGreenTheindicatorislitwhentheboardisoperatingproperly.

ALMRedTheindicatorislitiftheboardproducesanalarm.

TechnicalParameters

ForthetechnicalparametersoftheRAC-PIU-16CE1board,refertoT able9-45.

Table9-45TechnicalParametersoftheRAC-PIU-16CE1Board

ParameterSpecication

SilkscreennameRAC-PIU-16CE1

Dimensions(W×H×D)7.76in.×0.79in.×6.9in.(197.2mm×19.92mm×175mm)

Powerconsumption16W

Weight1.19lb.(0.54kg)

Rate2.048Mbps×16

9.16RAC-PIU-16CE1-CES

Overview

RAC-PIU-16CE1-CESboardprovidesthefollowingfunctions:

lProvides16channelized/unchannelizedE1interfaces.

lSupportstheprocessingofvariousservices,suchasTDM,PPPandML-PPP.

lSupportshotswapping.

lSupportsboardinformationqueryandtemperaturemonitoring.

lSupportsthe75Ωor120Ωconguration.

Panel

ForthepaneloftheRAC-PIU-16CE1-CESboard,seeFigure9-16.

Figure9-16FrontPaneloftheRAC-PIU-16CE1-CESBoard

InterfaceProperties

FortheinterfacepropertiesoftheRAC-PIU-16CE1-CESboard,refertoT able9-46.

9-25

SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential
