Chapter9LineInterfaceBoards

9.20RAC-PIU-02CP3-SFP

Overview

RAC-PIU-02CP3-SFPboardprovidesthefollowingfunctions:

lSupports2-wirechannelizedOC-3/STM-1POSapplications.

lRestorestheopticalchanneldataclockandprovidingittoanMPFUboardforrefer-

ence.

lSupportstheprocessingofvariousservices,suchasPPPandHDLC.

lSupportshotswapping.

lSupportsboardinformationqueryandtemperaturemonitoring.

Panel

ForthepaneloftheRAC-PIU-02CP3-SFPboard,seeFigure9-20.

Figure9-20FrontPaneloftheRAC-PIU-02CP3-SFPBoard

InterfaceProperty

TheRAC-PIU-02CP3-SFPboardusesSFPopticalmodules.Foradescriptionofthe

interfaceproperties,refertoT able9-58.

Table9-58InterfacePropertiesoftheRAC-PIU-02CP3-SFPBoard

PropertyDescription

ConnectortypeLC-typeSFPopticalmoduleinterface

OperationalmodeFullduplex

AppliedstandardSONETGR-253-CORE/ITU-TG.707

SupportedlinkprotocolPPP ,HDLC,FR,MPPP

Supportednetwork

protocol

Indicators

ForadescriptionoftheindicatorsoftheRAC-PIU-02CP3-SFPboard,refertoTable9-59.

Table9-59DescriptionoftheIndicatorsonthePaneloftheRAC-PIU-02CP3-SFPBoard

IndicatorColorDescription

RUNGreenTheindicatorislitwhentheboardisoperatingproperly.

ALMRedTheindicatorislitiftheboardproducesanalarm.

9-31

SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential
