ZXR10ZSRV2HardwareDescription
Table5-5FunctionsofthePowerButtonsoftheACPowerModuleoftheZXR10
2800-3EChassis
ButtonDescription
ON(—)DialthebuttontoONtoturnonthemodule.
OFF(O)DialthebuttontoOFFtoturnoffthepower.
TechnicalParameters
FortechnicalparametersofarectieroftheACpowermoduleoftheZXR102800-3E
chassis,refertoTable5-6.
Table5-6TechnicalParametersoftheACPoweroftheZXR102800-3EChassis
ParameterDescription
Dimension(width×height
×depth)
3.15in.×1.57in.×6.89in.(80mm×40mm×175mm)
Weight0.68kg
Rangeoftheinputvoltage100VAC–240VAC
InputACfrequency50Hz–60Hz
Ratedoutputpower250W
5.2.2DCPowerModule
Panel
Figure5-6showsthepaneloftheDCpowermoduleofaZXR102800-3Echassis.
Figure5-6PaneloftheDCPowerModule
Indicators
ForfunctionsoftheindicatorsontheDCpowermoduleoftheZXR102800-3Echassis,
refertoT able5-7.
5-6
SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential
