Chapter9LineInterfaceBoards

Table9-7TechnicalParametersoftheRAC-SPIU-02UE1-75Board

ParameterSpecication

SilkscreennameRAC-SPIU-02UE1-75

Dimensions(W×H×D)3.86in.×0.79in.×6.9in.(98.1mm×19.92mm×175mm)

Powerconsumption6W

Weight0.53lb.(0.24kg)

Rate2.048Mbps×2

9.3RAC-SPIU-02CE1-120

Overview

RAC-SPIU-02CE1-120boardprovidesthefollowingfunctions:

lProvidestwochannelized/unchannelizedE1(120ohm)interfaces.

lRestoresthelineclockandprovidingittoanMPFUboardforreference.

lSupportstheprocessingofvariousservices,suchasPPPandML-PPP.

lSupportshotswapping.

lSupportsboardinformationqueryandtemperaturemonitoring.

lSupportsthedelayedpower-onfunction.

Whentherouterispoweredon,alltheboardsarestartedup,causingahighpressure

onthepowersupply.Thedelayedpower-onfunctioncanreducetheelectriccurrent

impactcausedbytheboardsandprotectcomponentsfromdamageduetothe

instantaneoussurgecurrent.

Panel

ForthepaneloftheRAC-SPIU-02CE1-120board,seeFigure9-3.

Figure9-3FrontPaneloftheRAC-SPIU-02CE1-120Board

InterfaceProperty

TheRAC-SPIU-02CE1-120boardprovidesRJ48interfaces,anditonlysupports120ohm

E1interfaces.Foradescriptionoftheinterfaceproperties,refertoT able9-8.

Table9-8InterfacePropertiesoftheRAC-SPIU-02CE1-120Board

PropertyDescription

ConnectortypeRJ48

9-5

SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential
