ZXR10ZSRV2HardwareDescription

Table8-6FunctionsoftheIndicatorsonthePaneloftheRAC-DPIU-OSU-A2Board

IndicatorColorDescription

ALMRedIfthisindicatorissolidonorashing,theboardis

faulty.

RUNGreenIndicatesthattheboardisoperatingproperly.

Button

TheRAC-DPIU-OSU-A2boardprovidestwobuttonsonitspanel.Fortheirfunctions,refer

toTable8-7.

Table8-7FunctionsoftheButtonsonthePaneloftheRAC-DPIU-OSU-A2Board

ButtonDescription

RSTBoardresetbutton

PWRBoardpowerbutton

TechnicalParameters

FortechnicalparametersoftheRAC-DPIU-OSU-A2board,refertoTable8-8.

Table8-8TechnicalParametersoftheRAC-DPIU-OSU-A2Board

ParameterDescription

BoardnamesilkscreenRAC-DPIU-OSU-A2

Dimension(width×height×depth)7.76in.×1.58in.×6.9in.(197.2mm×40.24mm

×175mm)

Powerconsumption40W

Weight2.71lb.(1.23kg)

MemoryDefaultcapacity(byte)4Gor8G(optional)

HarddiskDefaultcapacity(byte)500Gor1T(optional)

8.3RAC-DPIU-FW-A

Overview

AsarewallboardoftheZXR103800-8andZXR102800-4,anRAC-DPIU-FW-Aboard

isinstalledinaslotforafull-heightDPIUinterfacecardandhasthefollowingfunctions:

lClassies,monitors,lters,andtransfersreceivedmessagesdependingon

applications.

lProvidesfourlinesofhigh-speedserialinterfacesfortheinternalgigabitEthernetand

onelineofelectricalinterfacefortheexternalgigabitEthernet.

lGEelectricalinterfacessupport10BASE-T/100BASE-TX/1000BASE-T .

8-4

SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential
