Chapter4

ZXR101800-2SChassis

TheZXR10ZSRV2seriesroutersarehighlyexiblebyusingthemodularstructure,and

theboardsandcomponentsarehotswappable.Theentirerouterconsistsofthechassis,

backplane,MPFU,lineinterfaceboards,powersupplymodules,andfanmodules.

TheZXR101800-2Sisadesktopproduct.ThepowersupplymoduleandMPFUarexed

inthechassis.Theserviceboardsareinstalledontherearpanelandtherearleading-out

modeisused.

TheZXR101800-2Shastwoextensiontypesconguredwithwirelessmodules:ZXR10

1800-2S(G)andZXR101800-2S(W).

lTheZXR101800-2S(G)hasabuilt-inLTEmodule,whereaSIMcardslotisavailable

forsupportingGSM,WCDMA,TD-SCDMA,orLTEnetworks.

lTheZXR101800-2S(W)hasabuilt-inWiFimoduleforsupportingtheWiFifunction.

TableofContents

Structure....................................................................................................................4-1

PowerSupply.............................................................................................................4-6

4.1Structure

4.1.1OverviewandStructure

Overview

TheheightoftheZXR101800-2Schassis(excludingtheantenna)is1U(1U=44.45mm),

andthedimension(width×height×depth)380mm×43.6mm×200mm.Foradescription

ofthemaincomponentsoftheZXR101800-2S,refertoTable4-1.

Table4-1DescriptionsoftheMainComponentsoftheZXR101800-2S

ComponentNameDescription

BoardareaTheZXR101800-2Sprovidesamaximumoftwolineinterface

cardslots.

MPFUTheMPFUoftheZXR101800-2Sisintegratedintothechassis

andcannotberemoved.

PowersupplymoduleThepowersupplymoduleoftheZXR101800-2Sisintegratedon

thedevice,andcannotberemovedorinstalled.

4-1

SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential
