ZXR10ZSRV2HardwareDescription

FrontPanel

ThefollowingdescribesthefrontviewandfrontpanelofaZXR102800-3Echassis.

lFigure5-1showsthefrontviewofaZXR102800-3Echassis.

Figure5-1FrontStructureGraphforaZXR102800-3EChassis

Note:

TheZXR102800-3E(G)submodeloftheZXR102800-3Echassissupportsthe

wirelessfunction,withabuilt-inwirelessmoduleandantennas.Ifthewireless

moduleisnotcongured,thechassisdoesnothaveanantenna.

lFigure5-2showsthefrontpanelofaZXR102800-3Echassis.

Figure5-2FrontPanelofaZXR102800-3EChassis

Foradescriptionofthefrontpanel,refertoTable5-2.

Table5-2DescriptionsofInterfacesontheFrontPanelofaZXR102800-3EChassis

PartTypeDescription

AntennainterfaceAntennaslot.

GEinterface24GEelectricalinterfaces,supportingtherouteswitchingfunction.

COMBOinterfacesTwoCombointerfaces.

USBinterfacesUSB2.0interfaces,whichareusedtostoreapplicationsandother

dataandsupportcommissioning.

Networkinterface(RJ45)Maintenancenetworkinterface(10M/100M/1000M),whichisused

forsystemcontrolandapplicationdownload.

5-2

SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential
