ZXR10ZSRV2HardwareDescription
Table9-83OpticalInterfacePropertiesoftheRAC-DPIU-16GE-12SFP4EBoard
PropertyDescription
ConnectortypeLC-typeSFPopticalmoduleinterface
OperationalmodeFullduplex
AppliedstandardIEEE802.3zGigabitEthernetstandard
SupportedframeformatEthernetframe
Supportednetwork
protocol
IP
Indicators
ForadescriptionoftheindicatorsoftheRAC-DPIU-16GE-12SFP4Eboard,refertoTable
9-84.
Table9-84DescriptionoftheIndicatorsonthePaneloftheRAC-DPIU-16GE-12SFP4E
Board
IndicatorColorDescription
RUNGreenTheindicatorislitwhentheboardisoperatingproperly.
ALMRedTheindicatorislitiftheboardproducesanalarm.
Electricalport
indicator
Green/YellowLinkstatus/datatransmissionindicatorsforfourGEelectrical
interfaces:
lIfthelinkisnormal,therightgreenindicatorislit.
lIfdataisbeingtransmitted,theleftyellowindicatorashes.
lIfthereisnodatabeingtransmittedornoconnection,the
indicatorsarenotlit.
LNK/ACT
Green/Yellow
Linkstatus/datatransmissionindicatorsfor12GEoptical
interfaces:
lIfthelinkisnormal,theindicatorislitingreen.
lIfdataisbeingtransmitted,theindicatorashesinyellow.
lIfthereisnodatabeingtransmittedornoconnection,the
indicatorisnotlit.
TechnicalParameters
ForthetechnicalparametersoftheRAC-DPIU-16GE-12SFP4Eboard,refertoTable9-85.
Table9-85TechnicalParametersoftheRAC-DPIU-16GE-12SFP4EBoard
ParameterSpecication
SilkscreennameRAC-DPIU-16GE-12SFP4E
Dimensions(W×H×D)7.76in.×1.58in.×6.9in.(197.2mm×40.24mm×175mm)
Powerconsumption36W
Weight0.6kg
9-44
SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential

Zte ZXR10 3800-8 Specifications

General

MAC Address Table Size	16K
VLAN	4K
MAC Address Table	16K
Packet Buffer	4 MB
Storage Temperature	-40°C to 70°C
Dimensions	440mm x 220mm x 44mm
Power Supply	AC: 100V~240V, 50/60Hz
Operating Temperature	0°C to 45°C
Operating Humidity	10% to 90% RH
Ports	8x 10/100/1000Base-T, 4x SFP
Power Consumption	Max 30W
