ZXR10ZSRV2HardwareDescription

lProvidestwounchannelizedE1(75ohm)interfaces.

lRestoresthelineclockandprovidingittoanMPFUboardforreference.

lSupportstheprocessingofvariousservices,suchasPPPandML-PPP.

lSupportshotswapping.

lSupportsboardinformationqueryandtemperaturemonitoring.

Panel

ForthepaneloftheRAC-SPIU-02UE1-75board,seeFigure9-2.

Figure9-2FrontPaneloftheRAC-SPIU-02UE1-75Board

InterfaceProperty

TheRAC-SPIU-02UE1-75boardprovidesmicrocoaxialinterfaces,anditonlysupports

75ohmnon-balancedE1interfaces.Foradescriptionoftheinterfaceproperties,referto

Table9-5.

Table9-5InterfacePropertiesoftheRAC-SPIU-02UE1-75Board

PropertyDescription

ConnectortypeMicrocoaxial

OperationalmodeFullduplex

AppliedstandardITU-TG.703,G.704

SupportedlinkprotocolPPP ,ML-PPP ,HDLC,FR

Supportednetwork

protocol

Indicators

ForadescriptionoftheindicatorsoftheRAC-SPIU-02UE1-75board,refertoT able9-6.

Table9-6DescriptionoftheIndicatorsonthePaneloftheRAC-SPIU-02UE1-75Board

IndicatorColorDescription

RUNGreenTheindicatorislitwhentheboardisoperatingproperly.

LNK1/LNK2Green

Theindicatorislitwhenthelinkisoperatingproperly,andis

notlitwhenthelinkisidle.

TechnicalParameters

ForthetechnicalparametersoftheRAC-SPIU-02UE1-75board,refertoT able9-7.

9-4

SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential
