AppendixB

OpticalModulesQuickTable

Overview

ZXR10ZSRV2routersusetheSFPopticalmodules,refertoT ableB-1.

TableB-1SFPOpticalModules

TypeExample

SFP(SmallForm-factorPluggable)

Indicators

AnopticalmodulealwayshastheACTandLNKindicators.Forindicatordescriptions,

refertoT ableB-2.

TableB-2OpticalModuleIndicatorDescriptions

IndicatorColorDescription

ACTGreenTransmissionstatusindicatorofanopticalport.Whendatais

beingtransmitted,thisindicatorashes.

LNKGreenPhysicalconnectionstatusindicatorofanopticalport.Ifthe

physicalconnectionoftheopticalportisnormal,thisindicatoris

on.Otherwise,thisindicatorisoff.

SFPAttributes

Fortheattributesofan155MSFPopticalmodule,refertoT ableB-3.

TableB-3155MSFPAttributes

AttributeParameters

Transmissiondistance

(km)

2154080100

Centralwavelength

(nm)

13101310131015501310

Referencewavelength

range(nm)

1260~15701261~13601263~13601480~15801480~1580

Transmittingoptical

powerrange(dBm)

-19~-14-15~-8-5~0-5~00~5

B-1

SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential
