ZXR10ZSRV2HardwareDescription

RJ45PinPCBCONSOLE

Signal

Direction

DB9PinPCDB9(Hole)

Signal

5GND—5GND

6RXD←3TXD

7DSR←4DTR

8RTS→8CTS

10.2.3EthernetCables

TherearetwotypesofEthernetcables,crossovercablesandstraight-throughcables.

Straight-throughEthernetcablesareusedinthefollowingcases:

lEthernetconnectionbetweenZXR10ZSRV2andalineconcentrator.

lEthernetconnectionbetweenZXR10ZSRV2andanEthernetswitch.

lEthernetconnectionbetweenacomputerandalineconcentrator.

lEthernetconnectionbetweenacomputerandanEthernetswitch.

CrossoverEthernetcablesareusedinthefollowingcases:

lEthernetconnectionbetweentwoZXR10ZSRV2devices.

lEthernetconnectionbetweenZXR10ZSRV2andacomputerEthernetcard.

lEthernetconnectionbetweentwolineconcentrators.

lEthernetconnectionbetweenalineconcentratorandanEthernetswitch.

lEthernetconnectionbetweentwoEthernetswitches.

lEthernetcardconnectionbetweentwocomputers.

AnEthernetcableconsistsofRJ45connectorsandaneight-wiretwistedpaircable.For

anoverviewoftheEthernetcable,seeFigure10-6.

Figure10-6Ethernetcable

1.Ethernetcableconnector2.StandardshieldedEthernet

cable

3.Cablelabel

Forthewiringsequenceofthestraight-throughEthernetcable,refertoTable10-6.

10-6

SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential
