Chapter10Cables

Device-end

Connectortype

Opposite-end

Connectortype

CableTypeCableUsage

LCLC

Single-mode

indooropticalber

Connectionbetweeninterfaceline

cards

LCSC

Multimodeindoor

opticalber

Connectionbetweeninterfaceline

cards

LCSC

Single-mode

indooropticalber

Connectionbetweenaninterfaceline

cardandothertypesofdevices

LCLC

Multimodeindoor

opticalber

Connectionbetweenaninterfaceline

cardandothertypesofdevices

InterfaceboardsoftheZXR10ZSRV2mainlyuseLC-typeconnectors,seeFigure10-8.

Figure10-8LC-typeFiberConnector

10.2.5SHDSLCables

AnSHDSLcableisaneight-coreCAT5e100-ohmnon-shieldedtwistedpaircable.One

endisconnectedtooneRJ45connector,andtheotherendisconnectedtofourRJ11

connectors.TheSHDSLcablescanbeusedfortransmittingmultipletypesofsignals,

includingvoice,data,andvideosignals.

ForanoverviewoftheSHDSLcable,seeFigure10-9.

Figure10-9SHDSLCable

1.RJ45connector2.Eight-coreCAT5e100-ohm

non-shieldedtwistedpair

cable

3.RJ11connector

10-9

SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential
