Chapter6ZXR101800-2EChassis
lAlarmsaregeneratedduetoahighoutputcurrent.
lAlarmsaregeneratedduetoahighorlowtemperature.
Caution!
TurnoffbothpowersuppliesbeforeinstallingandmaintainingtheZXR10ZSRV2.
6.2.1ACPowerModule
Panel
Figure6-5showsthepaneloftheACpowermoduleofaZXR101800-2Echassis.
Figure6-5PaneloftheACPowerModule
Indicators
ForfunctionsoftheindicatorsontheACpowermoduleoftheZXR101800-2Echassis,
refertoT able6-4.
Table6-4FunctionsoftheIndicatorsonthePaneloftheACPowerModuleofthe
ZXR101800-2EChassis
IndicatorNumberColorDescription
RUN1GreenThepowermoduleisoperatingproperly.
ALM1RedThepowermoduleisoperatingimproperly.
Buttons
ForfunctionsofthepowerbuttonsontheACpowermoduleoftheZXR101800-2Echassis,
refertoT able6-5.
Table6-5FunctionsofthePowerButtonsoftheACPowerModuleoftheZXR10
1800-2EChassis
ButtonDescription
ON(—)DialthebuttontoONtoturnonthemodule.
OFF(O)DialthebuttontoOFFtoturnoffthepower.
6-5
SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential
