Chapter5ZXR102800-3EChassis

PartTypeDescription

MicroUSBinterfacesConsoleinterfacesoftheMicroUSBmodel,whichhavethesame

functionsasthoseoftheCON/AUXinterfacesoftheRJ45model

butahigherpriority.Selecteitherone.

Serialinterface(RJ45)Debuggingserialinterfaces(Console/AUXinterfaces)oftheRJ45

model,whichareusedfordevicemanagementandfunction

conguration.

InterfaceforaSIMcardInterfacefora3GorLTESIMcard.

WIFIfunctionbutton.

Buttonforre-establishingaWIFIconnection.

Buttons

Systemresetbutton.

GreenindicatorsforlinkstatusoftwoCombointerfaces.

Redindicatorforsystemfaults.

Greenindicatorforsystemoperationstatus.

Indicators

Greenindicatorfortheoperationstatusofthe3GorLTEnetwork.

BackPanel

Figure5-3showsthebackpanelofaZXR102800-3Echassis.

Figure5-3BackPanelofaZXR102800-3EChassis

1.Slotforaninterfaceboard

oftheSPIUline

2.Powermodule3.Slotforaninterfaceboard

ofthePIU/SPIUline

5.1.2SlotDeployment

Figure5-4showsslotsandslotIDsonthebackofaZXR102800-3Echassis.

Figure5-4SlotsontheBackofaZXR102800-3EChassis

5-3

SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential
