ZXR10ZSRV2HardwareDescription

Table2-6IndicatorDescriptionsfortheZXR103800-8DCPowerSupplyModule

IndicatorNumberColorDescription

RUN1GreenIndicatesthatthepowersupplymodule

operatesproperly.

ALM1RedIndicatesthatthepowersupplymodulehas

analarm.

Buttons

ThereisonepowerbuttonontheZXR103800-8DCpowersupplymodule.Fora

descriptionofthebutton,refertoT able2-7.

Table2-7PowerButtonDescriptionfortheZXR103800-8DCPowerSupplyModule

ButtonDescription

ON(—)Powersonthepowersupplymodule.

OFF(O)Powersoffthepowersupplymodule.

TechnicalParameters

ForthetechnicalparametersoftheDCpowersupplymoduleoftheZXR103800-8,refer

toTable2-8.

Table2-8TechnicalParametersoftheDCPowerSupplyModuleoftheZXR103800-8

ParameterSpecication

Dimensions(height×width×

depth)

3.15in.×1.57in.×6.89in.(80mm×40mm×175mm)

Weight1.45lb.(0.52kg)

Inputvoltagerange-72VDCto-48VDC

Maximumoutputpower250W

Ratedinputcurrent8.5A

2.3FANModule

ThereisaverticalfanmoduleintheZXR103800-8chassis,whichconsistsoffourfans.

Thecoolairentersthechassisfromitslateralside,owstotheboardsandpowersupply

modules,andthenisblownoutfromtheotherside.

Thefanmodulecanautomaticallyadjustthefanspeedaccordingtotheequipment

operationandsupportsthestatusmonitoringandalarmfunctions.

ForthetechnicalspecicationsoftheZXR103800-8fanmodule,refertoTable2-9.

2-6

SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential
