ZXR10ZSRV2HardwareDescription
Figure10-12V.35/V.24DTECable(RA-DTE-DB50-34pole)
1.Device-endconnector
DB50
2.Network-endconnector
34pole(male)
ForanoverviewoftheV.35/V.24DCEcable(RA-DCE-DB50-34pole),seeFigure10-13.
Figure10-13V.35/V.24DCECable(RA-DCE-DB50-34pole)
1.Device-endconnector
DB50
2.Network-endconnector
34pole(female)
Foradescriptionofthesynchronous/asynchronousserialcabletypes,refertoT able10-12.
10-12
SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential
