Chapter10Cables

FortherelationshipbetweenDCpowercablecorewiresandpinpositions,refertoTable

10-2.

Table10-2CoreWiresofaDCPowerCable

EndAColorEndBTag

A1BlackB2-48VRTN

A3BlueB1-48V

Caution!

DCpowercablesoftheZXR10ZSRV2arededicatedcables.Itisforbiddentousethem

forotherpurposes.

10.1.2ACPowerCables

FortheoverviewofanACpowercableoftheZXR10ZSRV2,seeFigure10-2.

Figure10-2ACPowerCable

1.10Ainternationalstandard

3-pinflatmaleplug

2.3×0.75mm

powercable

(with3Ccertification)

3.10Ainternationalstandard

T-shapedfemaleplug

ForthemodelsandspecicationsoftheACpowercablesoftheZXR10ZSRV2,referto

Table10-3.

Table10-3TechnicalParametersofanACPowerCable

ItemDescription

10Ainternationalstandard3-pinatmaleplug Terminalmodel

10AinternationalstandardT-shapedfemaleplug

Cablemodel3×0.0012sq.in.(0.75mm

),with3Ccertication

10-3

SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential
