Chapter3

ZXR102800-4Chassis

TheZXR10ZSRV2seriesroutersarehighlyexiblebyusingthemodularstructure,and

theboardsandcomponentsarehotswappable.Theentirerouterconsistsofthechassis,

backplane,MPFU,lineinterfaceboards,powersupplymodules,andfanmodules.

TheZXR102800-4chassisusestheplatemetalstructure.Theboards,powersupply

modules,andfanmodulesareinstalledonthefrontpanel,andthefrontleading-outmode

(opticalberinterfaces)isused.ThewidthoftheZXR102800-4chassiscomplieswith

the19-inchstandardandcanbeinstalledinIEC297orETSIstandardcabinets.

TableofContents

Structure....................................................................................................................3-1

PowerSupply.............................................................................................................3-3

Fan............................................................................................................................3-6

3.1Structure

3.1.1OverviewandStructure

TheheightoftheZXR102800-4chassisis2U(1U=1.75in.=44.45mm),andthe

dimensions(width×height×depth)are17.41in.×3.46in.×7.88in.(442mm×88mm

×200mm).ForthemaincomponentsoftheZXR102800-4chassis,seeFigure3-1.

Figure3-1MainComponentsontheFrontSideoftheZXR102800-4Chassis

ForthefrontviewoftheZXR102800-4chassis,seeFigure3-2.

3-1

SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential
