Chapter6ZXR101800-2EChassis

ComponentTypeDescription

MicroUSBinterfacesConsoleinterfacesoftheMicroUSBmodel,whichhavethesame

functionsasthoseoftheCON/AUXinterfacesoftheRJ45model

butahigherpriority.Selecteitherone.

Serialinterfaces(RJ45)Debuggingserialinterfaces(Console/AUXinterfaces)oftheRJ45

model,whichareusedtomanageroutersandcongurefunctions.

InterfaceforaSIMcardInterfacefora3GorLTESIMcard.

WIFIfunctionbutton.

Buttonforre-establishingaWIFIconnection.

Buttons

Systemresetbutton.

GreenindicatorsforlinkstatusesoftwoCombointerfaces.

Redindicatorforsystemfaults.

Greenindicatorforsystemoperationstatus.

Indicators

Greenindicatorfortheoperationstatusofa3GorLTEnetwork.

BackPanel

Figure6-3showsthebackpanelofaZXR101800-2Echassis.

Figure6-3BackPanelofaZXR101800-2EChassis

1.SlotsforSPIUlineinterface

boards

2.Powermodules

6.1.2Slots

Figure6-4showsslotsandslotIDsonthebackofaZXR101800-2Echassis.

Figure6-4SlotsontheBackofaZXR101800-2EChassis

AZXR101800-2Echassishasastructuresuitableforhorizontalinstallation.Twoservice

boardslotsaredesignedforthechassis,whicharenumberedas0-1inorder.Slots0and

1areusedtoinstallSPIUinterfaceboards.

6-3

SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential
