Chapter9LineInterfaceBoards

Table9-53DescriptionoftheIndicatorsonthePaneloftheRAC-PIU-02P3-SFPBoard

IndicatorColorDescription

RUNGreenTheindicatorislitwhentheboardisoperatingproperly.

ALMRedTheindicatorislitiftheboardproducesanalarm.

LNK/ACTGreen/Yellow

Linkstatus/datatransmissionindicator:

lIfthelinkisnormal,theindicatorislitingreen.

lIfdataisbeingtransmitted,theindicatorashesin

yellow.

lIfthereisnodatabeingtransmittedornoconnection,

theindicatorisnotlit.

TechnicalParameters

ForthetechnicalparametersoftheRAC-PIU-02P3-SFPboard,refertoT able9-54.

Table9-54TechnicalParametersoftheRAC-PIU-02P3-SFPBoard

ParameterSpecication

SilkscreennameRAC-PIU-02P3-SFP

Dimensions(W×H×D)7.76in.×0.79in.×6.9in.(197.2mm×19.92mm×175mm)

Powerconsumption16.5W

Weight1.19lb.(0.54kg)

Rate155.52Mbps×2

9.19RAC-PIU-04P3-SFP

Overview

RAC-PIU-04P3-SFPboardprovidesthefollowingfunctions:

lProvidesfourOC-3/STM-1interfacestoimplementPOSapplications.

lSupportstheprocessingofvariousservices,suchasPPPandHDLC.

lSupportshotswapping.

lSupportsboardinformationqueryandtemperaturemonitoring.

Panel

ForthepaneloftheRAC-PIU-04P3-SFPboard,seeFigure9-19.

Figure9-19FrontPaneloftheRAC-PIU-04P3-SFPBoard

9-29

SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential
