ZXR10ZSRV2HardwareDescription

Figure10-15120ΩBalancedTwisted-PairCable

1.Device-endconnector

DB50

2.8-coremicro-coaxialA

3.8-coremicro-coaxialB

4.Pin1atendA

5.Pin25atendA

6.Pin50atendA

7.Pin26atendA

Forthecorrespondencerelationshipsbetweentheend-Apinsandtheend-B1coresofthe

120Ωbalancedtwisted-paircable,refertoT able10-16.

Table10-16CorrespondenceRelationshipsBetweentheEnd-APinsandEnd-B1Cores

ofthe120ΩBalancedTwisted-PairCable

PinatEndAEndB1(16-CoreCableA)Signal

25BlueR1+

50White

Twistedpair

R1–

24OrangeT1+

49White

Twistedpair

T1–

23GreenR2+

48White

Twistedpair

R2–

22BrownT2+

47White

Twistedpair

T2–

21GreyR3+

46White

Twistedpair

R3–

20BlueT3+

45Red

Twistedpair

T3–

19OrangeR4+

44Red

Twistedpair

R4–

10-16

SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential
