Chapter9LineInterfaceBoards

Table9-40InterfacePropertiesoftheRAC-PIU-04UE1-120Board

PropertyDescription

ConnectortypeRJ48

OperationalmodeFullduplex

AppliedstandardITU-TG.703,G.704

SupportedlinkprotocolPPP ,ML-PPP ,HDLC,FR

Supportednetwork

protocol

Indicators

ForadescriptionoftheindicatorsoftheRAC-PIU-04UE1-120board,refertoTable9-41.

Table9-41DescriptionoftheIndicatorsonthePaneloftheRAC-PIU-04UE1-120Board

IndicatorColorDescription

RUNGreenTheindicatorislitwhentheboardisoperatingproperly.

ALMRedTheindicatorislitiftheboardproducesanalarm.

LNK1–LNK4Green

Theindicatorislitwhenthelinkisoperatingproperly,andis

notlitwhenthelinkisidle.

TechnicalParameters

ForthetechnicalparametersoftheRAC-PIU-04UE1-120board,refertoT able9-42.

Table9-42TechnicalParametersoftheRAC-PIU-04UE1-120Board

ParameterSpecication

SilkscreennameRAC-PIU-04UE1-120

Dimensions(W×H×D)7.76in.×0.79in.×6.9in.(197.2mm×19.92mm×175mm)

Powerconsumption11W

Weight1.19lb.(0.54kg)

Rate2.048Mbps×4

9.15RAC-PIU-16CE1

Overview

RAC-PIU-16CE1boardprovidesthefollowingfunctions:

lProvides16channelized/unchannelizedE1interfaces.

lSupportstheprocessingofvariousservices,suchasPPPandML-PPP.

lSupportshotswapping.

9-23

SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential
