ZXR10ZSRV2HardwareDescription
FrontPanel
Figure4-1showsthefrontviewoftheZXR101800-2S.
Figure4-1ZXR101800-2SFrontView
Note:
BothoftheZXR101800-2S(G)andtheZXR101800-2S(W)supportthewirelessfunction.
Eachofthemisconguredwithawirelessmoduleandapairofantennas.Ifnowireless
moduleiscongured,thechassishasnoantenna.
Figure4-2showsthepanelviewoftheZXR101800-2S.
Figure4-2ZXR101800-2SFrontPanel
ForadescriptionoftheZXR101800-2Sfrontpanel,refertoT able4-2.
Table4-2ZXR101800-2SFrontPanelDescriptions
ComponentSilkScreenNameDescription
USB1 USBinterfaces
USB2
USB2.0interface,usedforstoringinstallation
packagesandotherdata,supporting3Gextension
andcommissioningthroughUSB.
4-2
SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential
