Chapter2ZXR103800-8Chassis

Buttons

ThereisonepowerbuttonontheZXR103800-8ACpowersupplymodule.Fora

descriptionofthebutton,refertoT able2-4.

Table2-4PowerButtonDescriptionfortheZXR103800-8ACPowerSupplyModule

ButtonDescription

ON(—)Powersonthepowersupplymodule.

OFF(O)Powersoffthepowersupplymodule.

TechnicalParameters

ForthetechnicalparametersoftheACpowerrectieroftheZXR103800-8,refertoTable

2-5.

Table2-5TechnicalParametersoftheACPowerRectieroftheZXR103800-8

ParameterSpecication

Dimensions(height×

width×depth)

3.15in.×1.57in.×6.89in.(80mm×40mm×175mm)

Weight0.68kg

Inputvoltagerange100VACto240VAC

ACinputfrequency50Hzto60Hz

Ratedoutputpower250W

2.2.2DCPowerSupplyModule

Panel

ForthefrontviewoftheDCpowersupplymoduleoftheZXR103800-8,seeFigure2-5.

Figure2-5PaneloftheDCPowerSupplyModule

Indicators

ForadescriptionoftheZXR103800-8DCpowersupplyindicators,refertoTable2-6.

2-5

SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential
