Chapter9LineInterfaceBoards
lProvidesfourGEelectricalinterfacesandoneGEopticalinterface.
lTheGEelectricalinterfacessupport10BASE-T/100BASE-TX/1000BASE-TXandthe
GEopticalinterfacesupports1000BASE-X.
lSupportshotswapping.
lSupportsboardinformationqueryandtemperaturemonitoring.
Panel
ForthepaneloftheRAC-PIU-05GE-4E1SFPboard,seeFigure9-24.
Figure9-24FrontPaneloftheRAC-PIU-05GE-4E1SFPBoard
InterfaceProperties
TheRAC-PIU-05GE-4E1SFPboardprovideselectricalandopticalinterfaces(GE1–GE5),
whicharenotdistinguishedbysilkscreenname.Theycanbedistinguishedbythe
interfaceoverviewandindicators.
ForadescriptionoftheGEelectricalinterfacepropertiesoftheRAC-PIU-05GE-4E1SFP
board,refertoTable9-70.
Table9-70GEElectricalInterfacePropertiesoftheRAC-PIU-05GE-4E1SFPBoard
PropertyDescription
ConnectortypeRJ-45
OperationalmodeFullduplex,Halfduplex
AppliedstandardIEEE802.3zGigabitEthernetstandard
SupportedframeformatEthernetframe
Supportednetwork
protocol
IP
TheRAC-PIU-05GE-4E1SFPboardusesSFPopticalmodules.Foradescriptionofthe
opticalinterfaceproperties,refertoTable9-71.
Table9-71OpticalInterfacePropertiesoftheRAC-PIU-05GE-4E1SFPBoard
PropertyDescription
ConnectortypeLC-typeSFPopticalmoduleinterface
OperationalmodeFullduplex
AppliedstandardIEEE802.3zGigabitEthernetstandard
SupportedframeformatEthernetframe
9-37
SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential

Zte ZXR10 3800-8 Specifications

General

MAC Address Table Size	16K
VLAN	4K
MAC Address Table	16K
Packet Buffer	4 MB
Storage Temperature	-40°C to 70°C
Dimensions	440mm x 220mm x 44mm
Power Supply	AC: 100V~240V, 50/60Hz
Operating Temperature	0°C to 45°C
Operating Humidity	10% to 90% RH
Ports	8x 10/100/1000Base-T, 4x SFP
Power Consumption	Max 30W
