Chapter8GeneralProcessingBoards

8.2RAC-DPIU-OSU-A2

Overview

AsthegeneralprocessingboardoftheZXR102800-4andZXR103800-8,an

RAC-DPIU-OSU-A2boardisinstalledinaslotforafull-heightDPIUinterfacecardand

hasthefollowingfunctions:

lClassies,monitors,lters,andtransfersreceivedmessagesdependingon

applications.

lProvidesfourlinesofhigh-speedserialinterfacesfortheinternalgigabitEthernetand

onelineofelectricalinterfacefortheexternalgigabitEthernet.

lGEelectricalinterfacessupport10BASE-T/100BASE-TX/1000BASE-T .

Panel

ForthepaneloftheRAC-DPIU-OSU-A2boardofthegeneralprocessingboard,seeFigure

8-2.

Figure8-2PanelofanRAC-DPIU-OSU-A2Board

Interfaces

ForadescriptionofinterfacesontheRAC-DPIU-OSU-A2board,refertoTable8-5.

Table8-5DescriptionofInterfacesontheRAC-DPIU-OSU-A2Board

InterfaceTypeDescription

Networkinterface(RJ45)Servicenetworkinterface,a10/100/1000BASE-Telectrical

interface.

Serialinterface(RJ45)SerialinterfaceinterconnectedwithaPC.

VGAinterface(DB15)X86VGAoutputinterface.

USBinterfacesUSB2.0interfacesusedtoinstalltheX86system.

Indicator

TheRAC-DPIU-OSU-A2boardprovidesmultipleLEDindicatorsonitspanel.Fortheir

functions,refertoTable8-6.

8-3

SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential
