ZXR10ZSRV2HardwareDescription

Table9-67InterfacePropertiesoftheRAC-PIU-08GE-SFPBoard

PropertyDescription

ConnectortypeLC-typeSFPopticalmoduleinterface

OperationalmodeFullduplex

AppliedstandardIEEE802.3zGigabitEthernetstandard

SupportedlinkprotocolEthernetFrame

Supportednetwork

protocol

Ethernet

Indicators

ForadescriptionoftheindicatorsoftheRAC-PIU-08GE-SFPboard,refertoT able9-68.

Table9-68DescriptionoftheIndicatorsonthePaneloftheRAC-PIU-08GE-SFPBoard

IndicatorColorDescription

RUNGreenTheindicatorislitwhentheboardisoperatingproperly.

ALMRedTheindicatorislitiftheboardproducesanalarm.

LNKGreen

Linkstatus/datatransmissionindicator:

lIfthelinkisnormal,theindicatorislitingreen.

lIfdataisbeingtransmitted,theindicatorashesin

yellow.

lIfthereisnodatabeingtransmittedornoconnection,

theindicatorisnotlit.

TechnicalParameters

ForthetechnicalparametersoftheRAC-PIU-08GE-SFPboard,refertoT able9-69.

Table9-69TechnicalParametersoftheRAC-PIU-08GE-SFPBoard

ParameterSpecication

SilkscreennameRAC-PIU-08GE-SFP

Dimensions(W×H×D)7.76in.×0.79in.×6.9in.(197.2mm×19.92mm×175mm)

Powerconsumption15W

Weight1.19lb.(0.54kg)

Rate1GE×8

9.24RAC-PIU-05GE-4E1SFP

Overview

RAC-PIU-05GE-4E1SFPboardprovidesthefollowingfunctions:

9-36

SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential
