IndicatorColorDescription

LNK/ACTGreen/Yellow

Linkstatus/datatransmissionindicator:

lIfthelinkisnormal,theindicatorislitingreen.

lIfdataisbeingtransmitted,theindicatorashesin

yellow.

lIfthereisnodatabeingtransmittedornoconnection,

theindicatorisnotlit.

TechnicalParameters

ForthetechnicalparametersoftheRAC-PIU-02CP3-SFPboard,refertoT able9-60.

Table9-60TechnicalParametersoftheRAC-PIU-02CP3-SFPBoard

ParameterSpecication

SilkscreennameRAC-PIU-02CP3-SFP

Dimensions(W×H×D)7.76in.×0.79in.×6.9in.(197.2mm×19.92mm×175mm)

Powerconsumption16.5W

Weight1.19lb.(0.54kg)

Rate155.52Mbps×2

9.21RAC-PIU-04CP3-SFP

Overview

RAC-PIU-04CP3-SFPboardprovidesthefollowingfunctions:

lProvidesfourchannelizedOC3/STM-1interfacestoimplementPacketOver

SONET/SDHapplications.

lRestorestheopticalchanneldataclockandprovidesittoanMPFUboardfor

reference.

lSupportstheprocessingofvariousservices,suchasPPPandHDLC.

lSupportshotswapping.

lSupportsboardinformationqueryandtemperaturemonitoring.

Panel

ForthepaneloftheRAC-PIU-04CP3-SFPboard,seeFigure9-21.

Figure9-21FrontPaneloftheRAC-PIU-04CP3-SFPBoard

9-32

SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential
