MP-1xx SIP User’s Manual 5. Configuring the MP-1xx
Version 4.4 111 March 2005
Table 5-30 describes the SNMP parameters that can only be configured via the ini file.
Table
5-30: SNMP ini File Parameters
ini File Parameter Name Description
SNMPPort
The device’s local UDP port used for SNMP Get/Set commands.
The range is 100 to 3999.
The default port is 161.
SNMPTrustedMGR_x
Up to five IP addresses of remote trusted SNMP managers from which the
SNMP agent accepts and processes get and set requests.
Note 1: If no values are assigned to these parameters any manager can
access the device.
Note 2: Trusted managers can work with all community strings.
SNMP Community String Parameters
SNMPReadOnlyCommunityString_x
Read-only community string (up to 19 chars).
The default string is “public”.
SNMPReadWriteCommunityString_x
Read-write community string (up to 19 chars).
The default string is “private”.
SNMPTrapCommunityString_x
Community string used in traps (up to 19 chars).
The default string is “trapuser”.
SetCommunityString
Note: Obsolete parameter, use
SNMPReadWriteCommunityString_x
instead.
SNMP community string (up to 19 chars).
Default community string for read “public”, for set & get “private”.
SNMPManagerIP
Note: Obsolete parameter, use
SNMPManagerTableIP_x instead.
IP address (in dotted format notation) for the computer that is used as the first
SNMP Manager. The SNMP Manager is a device that is used for receiving
SNMP Traps.
Note 1: To enable the device to send SNMP Traps, set the ini file parameter
SNMPManagerIsUsed to 1.
Note 2: If you want to use more than one SNMP manger, ignore this parameter
and use the parameters ‘SNMPManagerTableIP_x’ instead.
