MP-1xx SIP User’s Manual E. Customizing the MP-1xx Web Interface
Version 4.4 217 March 2005
E.4 Modifying ini File Parameters via the Web AdminPage
To modify ini file parameters via the AdminPage, take these 6 steps:
1. Access the MP-1xx Embedded Web Server (refer to Section 5.5 on page 40).
2. In the URL field, append the suffix ‘AdminPage’ (note that it’s case-sensitive) to the IP
address, e.g., http://10.1.229.17/AdminPage.
3. Click the INI Parameters option, the INI Parameters screen is displayed (shown in Figure
E-4).
Figure E-4: INI Parameters Screen
4. In the Parameter Name dropdown list, select the required ini file parameter.
5. In the Enter Value field to the right, enter the parameter’s new value.
6. Click the Apply new value button to the right; the INI Parameters screen is refreshed, the
parameter name with the new value appears in the fields at the top of the screen and the
Output Window displays a log displaying information on the operation.
Note: You cannot load the image files (e.g., logo/background image files) to the
device by choosing a file name parameter in this screen.
