MP-1xx SIP
MP-1xx SIP User’s Manual 228 Document #: LTRT-65404
Figure F-10: Call Progress Tone Properties
[CALL PROGRESS TONE #1]
Tone Type=1
Low Freq [Hz]=350
High Freq [Hz]=440
Low Freq Level [-dBm]=0
High Freq Level [-dBm]=0
First Signal On Time [10msec]=0
First Signal Off Time [10msec]=0
Second Signal On Time [10msec]=0
Second Signal Off Time [10msec]=0
• Information related to possible matches of each tone with the CPTWizard’s internal database
of well-known tones. This information is specified as comments in the file, and is ignored by
the TrunkPack Downloadable Conversion utility.
Figure F-11: Call Progress Tone Database Matches
# Recorded tone: Busy Tone (automatic configuration)
## Matches: PBX name=ITU Anguilla, Tone name=Busy tone
## Matches: PBX name=ITU Antigua and Barbuda, Tone name=Busy tone
## Matches: PBX name=ITU Barbados, Tone name=Busy tone
## Matches: PBX name=ITU Bermuda, Tone name=Busy tone
## Matches: PBX name=ITU British Virgin Islan, Tone name=Busy tone
## Matches: PBX name=ITU Canada, Tone name=Busy tone
## Matches: PBX name=ITU Dominica (Commonweal, Tone name=Busy tone
## Matches: PBX name=ITU Hongkong, China, Tone name=Busy tone
## Matches: PBX name=ITU Jamaica, Tone name=Busy tone
## Matches: PBX name=ITU Korea (Republic of), Tone name=Busy tone
## Matches: PBX name=ITU Montserrat, Tone name=Busy tone
• Information related to matches of all tones recorded with the CPTWizard’s internal database.
The database is scanned to find one or more PBX definitions that match all recorded tones
(i.e., dial tone, busy tone, ringing tone, reorder tone and any other manually-recorded tone –
all match the definitions of the PBX). If a match is found, the entire PBX definition is reported
(as comments) in the ini file using the same format.
Figure F-12: Full PBX/Country Database Match
## Some tones matched PBX/country Audc US
## Additional database tones guessed below (remove #'s to use).
#
# # Audc US, US Ringback tone
# [CALL PROGRESS TONE #5]
# Tone Type=2
# Low Freq [Hz]=450
# High Freq [Hz]=500
# Low Freq Level [-dBm]=0
# High Freq Level [-dBm]=0
# First Signal On Time [10msec]=180
# First Signal Off Time [10msec]=450
# Second Signal On Time [10msec]=0
# Second Signal Off Time [10msec]=0
Note 1: If a match is found in the database, consider using the database’s definitions
instead of the recorded definitions, as they might be more accurate.
Note 2 For full operability of the MP-1xx/FXO gateway, it may be necessary to edit
this file and add more Call Progress Tone definitions. Sample Call Progress
Tones ini files are available in the release package.
Note 3: When the CPT ini file is complete, use the TrunkPack Downloadable
Conversion utility to create a loadable CPT dat file. After loading this file to
the gateway, repeat the automatic detection procedure discussed above,
and verify that the gateway detects all four Call Progress Tones correctly.
