MP-1xx SIP User’s Manual 5. Configuring the MP-1xx
Version 4.4 95 March 2005
Table 5-21: Automatic Dialing ini File Parameter
Parameter Name in ini File Parameter Format
TargetOfChannelX
TargetOfChannel<Port> = <Phone>,<Mode>
For example:
TargetOfChannel0 = 1001,1
TargetOfChannel3 = 911,2
Note 1: The numbering of channels starts with 0.
Note 2: Define this parameter for each gateway port you want to use for
Automatic Dialing.
Note 3: This parameter can appear up to 8 times for MP-108 gateways and up
to 24 times for MP-124 gateways.
5.8.8.3 Caller ID
Use the Caller Display Information screen to send (to IP) Caller ID information when a call is
made using the VoIP gateway (relevant to both FXS and FXO). The person receiving the call can
use this information for caller identification. The information on this table is sent in an INVITE
message in the ‘From’ header. For information on Caller ID restriction according to destination /
source prefixes refer to Section
5.8.3 on page 68.
Note: If Caller ID name is detected on an FXO line (EnableCallerID = 1), it is used
instead of the Caller ID name defined in this table (FXO gateways only).
To configure the Caller ID table, take these 6 steps:
1. Open the ‘Caller Display Information’ screen (Protocol Management menu > Endpoint
Settings submenu > Caller ID option); the ‘Caller Display Information’ screen is displayed.
Figure
5-23: Caller Display Information Screen
2. In the Caller ID/Name field, enter the Caller ID string. The Caller ID string can contain up to
18 characters.
Note that when the FXS gateway receives “Private” or “Anonymous” strings in the ‘From’
header, it doesn’t send the calling name or number to the Caller ID display.
