MP-1xx SIP User’s Manual 5. Configuring the MP-1xx
Version 4.4 115 March 2005
Figure 5-30: Channel Settings, Fax/Modem/CID Parameters
Table
5-32: Channel Settings, Fax/Modem/CID Parameters (continues on pages 115 to 116)
Parameter Description
Fax Transport Mode
[FaxTransportMode]
Fax Transport Mode that the gateway uses.
You can select:
Disable [0].
T.38 Relay [1] (default).
Bypass [2].
Events Only [3] = N/A.
Note: If parameter IsFaxUsed = 1, then FaxTransportMode is always set to 1
(T.38 relay).
Caller ID Transport Type
[CallerIDTransportType]
N/A.
Caller ID Type
[CallerIDType]
Defines one of the following standards for detection (FXO) and generation (FXS)
of Caller ID signals.
Bellcore [0] (default).
ETSI [1].
NTT [2].
British [4]
DTMF ETSI [16]
Denmark [17]
India [18]
Brazil [19]
Note: The Caller ID signals are generated/detected between the first and the
second rings.
V.21 Modem Transport Type
[V21ModemTransportType]
N/A.
V.22 Modem Transport Type
[V22ModemTransportType]
V.22 Modem Transport Type that the gateway uses.
You can select:
Transparent [0].
Relay [1] = N/A.
Bypass [2] (default).
