MP-1xx SIP User’s Manual 5. Configuring the MP-1xx
Version 4.4 113 March 2005
5.9.2 Configuring the Channel Settings
The Channels Settings screen enables you to set the VoIP gateway channel parameters, such as
Input and Output voice gain, Jitter buffer characteristics, Modem, Fax and DTMF transport
modes. These parameters are applied to all MP-1xx channels.
Note that several Channels Settings parameters can be configured per call using profiles (refer to
Section
5.8.5 on page 83).
To configure the Channel Settings parameters, take these 4 steps:
1. Open the ‘Channel Settings’ screen (Advanced Configuration menu > Channel Settings);
the ‘Channel Settings’ screen is displayed.
2. Configure the Channel Settings parameters according to Table
5-31, Table 5-32, Table 5-33
and Table
5-34.
3. Click the Submit button to save your changes.
4. To save the changes so they are available after a power fail refer to Section
5.12 on page
139.
Note 1: Those parameters contained within square brackets are the names used to
configure the parameters via the ini file.
Note 2: Channel parameters are changeable on-the-fly. Changes take effect from
next call.
Figure 5-29: Channel Settings, Voice Settings Parameters
