MP-1xx SIP User’s Manual 5. Configuring the MP-1xx
Version 4.4 135 March 2005
Figure 5-46: Load a CPT File Screen
7. Follow the same procedure you followed when loading the ini file (refer to Step
6). The same
procedure applies to the ‘Load a VP file’ (not applicable to the MP-1xx gateway) screen and
‘Load a coefficient file’ screen.
8. In the ‘FINISH’ screen (refer to Figure
5-47), the Next button is disabled. Complete the
upgrade process by clicking Reset or Cancel.
Button Result
Reset
The MP-1xx ‘burns’ the newly loaded files to flash memory. The ‘Burning files to flash
memory’ screen appears. Wait for the ‘burn’ to finish. When it finishes, the ‘End Process’
screen appears displaying the burned configuration files (refer to Figure
5-48).
Cancel
The MP-1xx resets, utilizing the files previously stored in flash memory. (Note that these
are NOT the files you loaded in the previous Wizard steps).
