Page #320 background image
10-62
Cisco Nexus 7000 Series Hardware Installation and Reference Guide
OL-23069-07
Chapter 10 Installing or Replacing Components
Replacing the Front Doors and Frame Assembly on the Cisco Nexus 7010 Chassis
Replacing the Front Doors and Frame Assembly on the Cisco
Nexus 7010 Chassis
If the front door and frame assembly are already attached to the chassis when you need to ship the chassis
or move the chassis from one rack to another, you should remove the front doors and frame assembly for
safer and easier handling of the chassis.
This section describes how to remove and install the front doors and frame assembly, and it includes the
following topics:
Required Tools, page 10-62
Removing the Front Doors and Frame Assembly, page 10-62
Installing the Front Doors and Frame Assembly, page 10-67
Required Tools
You need a flat-blade or number 2 Phillips-head screwdriver to loosen or tighten the screws that hold the
frame members to the chassis.
Removing the Front Doors and Frame Assembly
Removing the optional front doors and frame assembly involves removing the side frames from the EMI
frame, removing the bottom frame assembly, and removing the two front doors.
Note If you are installing a new chassis, you do not need to perform this task because the chassis is not shipped
with these assemblies attached to it.
To remove the front doors and frame assemblies, follow these steps:
Step 1 Remove the two lower side frames from the EMI air filter frame by first removing the EMI panel from
the chassis, and then unscrewing the side frame pieces. When done, replace the EMI frame on the
chassis. The following steps explain each of these tasks:
a. On the EMI panel, which covers the air intake area on the lower front side of the chassis, loosen and
completely unscrew each of the four captive screws that hold the panel to the chassis.
b. Pull the EMI panel away from the chassis, along with the attached side frame members and optional
air filter (if attached) (see Figure 10-18).
