Appendix E Repacking the Cisco Nexus 7000 Series Switch for Shipment
Repacking the System Components
Step 16 Place the four sided box around the chassis and the top layer of the pallet. (see Callout 5 in Figure E-3).
Step 17 Place the accessories tray inside the chassis box and on top of the chassis padding (see Callout 6 in
Figure E-3).
Step 18 Place the accessory kit and the front-door kit in the accessories box (see Callout 7 in Figure E-3).
Step 19 Place the cardboard top on the chassis box (see callout 8 in Figure E-3).
Step 20 Place four edge protectors along the top edges of the cardboard top where you will be placing the packing
straps (see Callout 9 in Figure E-3).
Step 21 Fasten the top of the box to the chassis box and pallet with two packing straps (see Callout 10 in
Figure E-3).
Repacking the Cisco Nexus 7010 Switch
If you do not have the original packing materials for the Cisco Nexus 7010 switch, you must order
another set of these materials (order part number is N7K-C7010-SHPPKG=).
Caution Do not subject the pallet, switch, or package to water or moisture.
To repack the Cisco Nexus 7010 switch, follow these steps:
Step 1 Turn the power switch on each power supply to standby (STBY). The OUTPUT LED turns off.
Step 2 For each AC power supply , remove the power cords as follows:
a. Remove the one or two power plugs from the power source. All of the power supply LEDs turn off.
b. If you are removing a 6-kW AC power supply, unscrew the screw on the cable retention device and
pull the one or two plugs off the power supply.
Note For a 7.5-kW power supply, you cannot remove the power cords from them because they are
permanently attached.
Step 3 For each DC power supply, shut off the input power and remove the power cords as follows:
a. Turn off the DC input power by manually turning off each input circuit at its circuit breaker.
Warning
Before performing any of the following procedures, ensure that power is removed from the DC circuit.
Statement 1003
b. Verify that the input power is completely off by making sure that all of the LEDs on the DC power
supplies are off.
c. Detach each of the power cables from the powered down DC power source or DC power interface
unit (PIU).
