Appendix D Chassis and Module LEDs
I/O Module LEDs
I/O Module LEDs
Table D-3 describes the I/O module LEDs.
Table D-3 I/O Module LEDs
LED Status Description
ID Flashing blue The operator has activated this LED to identify this module in the chassis.
Off This module is not being identified.
Status Green All diagnostics pass. The module is operational (normal initialization
sequence).
Red The module has detected a slot ID parity error and will not power on or boot up.
or
The module is not fully inserted, and it is not making a reliable connection with
the supervisor.
or
The module has failed diagnostic tests and has powered down.
Flashing red The switch has just been powered on, and the module is resetting.
or
The module is resetting and both ejector levers are out.
or
The module has been inserted during the initialization process.
or
The module could not power up because of insufficient power.
or
An overtemperature condition has occurred. A major temperature threshold has
been exceeded during environmental monitoring.
Off The module is not receiving power.
Link (for each port) Green The port is active (the link is connected and active).
Orange The port is disabled by the operator or is not initializing.
Flashing orange The port is faulty and disabled.
Off The port is not active or the link is not connected.

Cisco Nexus 7000 Specifications

General

Chassis Type	Modular
Product Type	Switch
Power Supply	AC or DC
Cooling	Redundant, hot-swappable fan trays
Management	CLI, SNMP
Form Factor	Modular chassis
Interfaces/Ports	Varies by module
Product Series	Nexus 7000
Port Density	Varies by module
Redundancy	Power supply, fan, supervisor engine
Management Interfaces	Console, Ethernet
Security Features	ACLs, port security
Virtualization Support	VRF
Operating Temperature	0 to 40°C (32 to 104°F)
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Humidity	5% to 95% non-condensing
