A-15
Cisco Nexus 7000 Series Hardware Installation and Reference Guide
OL-23069-07
Appendix A Technical Specifications
Power Supply Cable Specifications
Power Supply Cable Specifications
For power supply cable specifications, see the following tables:
• Table A-16 for the 3-kW or 6-kW AC power supplies
• Table A-17 on page A-19 for the 7.5-kW AC power supplies
• Table A-18 on page A-20 for the 3-kW DC power supplies
• Table A-19 on page A-20 for the 6-kW DC power supplies
.
Table A-15 Power Availability for 6.0-kW DC Power Supply Units
Power Inputs
Combined
Mode
Power
Supply
Redundancy
Mode
Input Source
Redundancy
Mode
Full
Redundancy
Mode
Dual inputs per power supply
1 power supply
2 power supplies
1
3 power supplies
1
4 power supplies
1
6,000 W
12,000 W
18,000 W
24,000 W
—
6,000 W
12,000 W
18,000 W
3,000 W
6,000 W
9,000 W
12,000 W
—
6,000 W
9,000 W
12,000 W
Single input per power supply
1 power supply
2 power supplies
1
3 power supplies
1
4 power supplies
1
3,000 W
6,000 W
9,000 W
12,000 W
—
3,000 W
6,000 W
9,000 W
—
—
—
—
—
—
—
—
1. The Cisco Nexus 7018 switch uses up to four 6-kW power supplies, the Cisco Nexus 7010 switch uses up to three 6-kW
power supplies, and the Cisco Nexus 7009 uses up to two 6-kW power supplies.
Table A-16 6-kW AC Power Supply Power Cords
Locale Power Cord Part Number Cord Set Rating
Power Cord
Reference
Illustration
Australia and New Zealand CAB-AC-16A-AUS 16A, 250 VAC Figure A-1
Peoples Republic of China CAB-AC-16A-CH 16A, 250 VAC Figure A-2
Continental Europe CAB-AC-2500W-EU 16A, 250 VAC Figure A-3
International CAB-AC-2500W-INT 16A, 250 VAC Figure A-4
Israel CAB-AC-2500W-ISRL 16A, 250 VAC Figure A-5
Japan and North America (non locking)
200-240 VAC operation
CAB-AC-2500W-US1 16A, 250 VAC Figure A-6
Japan and North America (locking)
200-240 VAC operation
CAB-AC-C6K-TWLK 16A, 250 VAC Figure A-7
