Appendix D Chassis and Module LEDs
Fan Tray LEDs
Fan Tray LEDs
Table D-7 describes the fan tray LEDs.
Off The AC or DC output power is outside the valid range.
Fault Off The AC or DC output voltage and power supply unit tests are okay.
Flashing red Self-diagnostic tests have failed or another power supply failure has
occurred.
ID Flashing blue The operator has activated this LED to identify this module in the chassis.
Off This module is not being identified.
Table D-6 Power Supply LEDs (continued)
LED Color Condition
Ta b l e D - 7 F a n Tr a y L E D s
LED LED Indication Condition
STATUS Green The fan tray is operational.
Flashing red One or more fans is running below the threshold speed.
The fan tray is receiving insufficient power.
Off No power is going to the fan tray.
ID Flashing blue The operator has activated this LED to identify this module in the
chassis.
Off This module is not being identified.

Cisco Nexus 7000 Specifications

General

Chassis Type	Modular
Product Type	Switch
Power Supply	AC or DC
Cooling	Redundant, hot-swappable fan trays
Management	CLI, SNMP
Form Factor	Modular chassis
Interfaces/Ports	Varies by module
Product Series	Nexus 7000
Port Density	Varies by module
Redundancy	Power supply, fan, supervisor engine
Management Interfaces	Console, Ethernet
Security Features	ACLs, port security
Virtualization Support	VRF
Operating Temperature	0 to 40°C (32 to 104°F)
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Humidity	5% to 95% non-condensing
