134 © 2001- 2008 D-Link Corporation. All Rights Reserved.
D-Link Unified Access System User Manual
Table 29 describes the fields you see on the Radio Summary page for the managed access
point status.
Viewing Detailed Managed Access Point Radio Information
You can view detailed information about each radio on the APs that the Unified Switch
manages on the Radio Detail page for the managed access point radio status.
Table 30 describes the fields you see on the Radio Detail page for the managed access point
status.
Table 29. Managed AP Radio Summary
Field Description
MAC Address The Ethernet address of the Unified Switch managed AP.
Location A location description for the AP, this is the value configured in the valid AP
database (either locally or on the RADIUS server).
Radio Indicates the radio interface and configured mode of the radio, if the radio is
disabled the radio mode will be displayed as Off instead of showing the
configured mode.
Channel If radio is operational, the current operating channel for the radio.
Transmit Power If radio is operational, the current transmit power for the radio.
Associated Clients Total count of clients associated on the physical radio, this is a sum of all the
clients associated to each VAP enabled on the radio.
Authenticated
Clients
Total number of clients currently associated to the AP that have been
authenticated. This is the sum of all authenticated clients for all the VAPs
enabled on the radio.
Table 30. Managed AP Radio Detail
Field Description
MAC Address -
Location
(Drop-down Menu)
Shows the MAC address and location of the AP to which the values on the
page apply. To view details about a different AP, select its MAC address
from the drop-down menu.
Radio Indicates the radio interface and configured mode of the radio, if the radio is
disabled the radio mode will be displayed as Off instead of showing the
configured mode.
Supported
Channels
The list of eligible channels the AP reported to the switch for channel
assignment. The list is based on country code, hardware capabilities, and any
configured channel limitations.
Channel If radio is operational, the current operating channel for the radio.
Associated Clients Total count of clients associated on the physical radio, this is a sum of all the
clients associated to each VAP enabled on the radio.
Authenticated
Clients
Total count of clients authenticated on the physical radio, this is a sum of all
the clients authenticated to each VAP enabled on the radio.
Transmit Power If radio is operational, the current transmit power for the radio.
Authenticated
Clients
Total count of clients authenticated clients on the physical radio, this is a sum
of all the clients authenticated to each VAP enabled on the radio.
